LABORATORY SAFETY SHOWER

Nadiso® Emergency Safety showers and eye wash stations are a necessary backup to minimize the effects of accident exposure to chemicals. The stations provide on the spot decontamination, allowing workers to flush away immediately after the hazardous substances exposure that can cause serious injury. Safety showers can also be used effectively in extinguishing clothing fires or for flushing contaminants off clothing

Category :

LABORATORY SAFETY SHOWER



A . Eye wash


Used for immediate, emergency flushing in the case of chemical exposures to the eyes preventing blindness.
The eye wash can be set in wall or counter top mounted for quick access to eye wash solution when the accident happens. For detail specification will be discussed separately.

  1. Safety shower (body shower with eye wash)

Safety shower used to flush contaminants from eyes, face, or entire body. Ideal for locations where lab, worker are subjected to harmful contaminants. For detail specification will be discussed separately.

PRODUCT CODE NDS R001
PRODUCT NAME Single Eye Wash
Body Solid Brass
Spray Head Soft rubber, softened water spray for eye   protection
Dust Cap Polypropylene
Switch Automatic trigger locking for easy hand-free use
Valve Non-return valve, shut off automatically
Hose Length 1.5 m, PVC Pipe with stainless steel wire braided, wrapped by PE Pipe relief from rust and leakage
Max Working Pressure 6 Bar
Min Working Pressure 4 Bar
Water Flow > 6 L/min



PRODUCT CODE NDS R002
PRODUCT NAME Double Outlet Eye Wash
Body Solid Brass
Spray Head Soft rubber, softened water spray for eye   protection
Dust Cap Polypropylene
Switch Automatic trigger locking for easy hand-free use
Valve Non-return valve, shut off automatically
Hose Length 1.5 m, PVC Pipe with stainless steel wire braided, wrapped by PE Pipe relief from rust and leakage
Max Working Pressure 6 Bar
Min Working Pressure 4 Bar
Water Flow > 10 L/min





PRODUCT CODE NDS R003
PRODUCT NAME Double Outlet Eye Wash With Bowl
Body Solid Brass
Spray Head Soft rubber, softened water spray for eye protection
Dust Cap Polypropylene
Switch Automatic trigger locking for easy hand-free use
Valve Non-return valve, shut off automatically
Hose Length 1.5 m, PVC Pipe with stainless steel wire braided, wrapped by PE Pipe relief from rust and leakage
Max Working Pressure 6 Bar
Min Working Pressure 4 Bar
Water Flow > 10 L/min



































PRODUCT CODE NDS R004
PRODUCT NAME Ceilling Mounted Body Shower
Body Solid Brass
Connection Material Stainless Steel 304
Shower Nozzle 70o soft rubber protecting cup and dust proof
Max Working Pressure 6 Bar
Min Working Pressure 4 Bar
Water Flow 80 L/min







PRODUCT CODE NDS R005
PRODUCT NAME Wall Mounted Body Shower
Body Solid Brass
Connection Material Stainless Steel 304
Shower Nozzle 70o soft rubber protecting cup and dust proof
Max Working Pressure 6 Bar
Min Working Pressure 4 Bar
Water Flow 80 L/min











PRODUCT CODE NDS R006
PRODUCT NAME Body with Eye/Face Shower and Bowl
Body Solid Brass
Connection Material Stainless Steel 304
Shower Nozzle 70o soft rubber protecting cup and dust proof
Max Working Pressure 6 Bar
Min Working Pressure 4 Bar
Water Flow



Head : 80 L/min

Double Outlet Eye Wash : 10 L/min
